1 x Sunsynk 8kw Inverter
1 x 10kw Sunsynk Battery
1 x Set Battery connectors
1 x 160A DC Disconnect Box
2 X 160A DC Fuses
Solar Panels can be added at any time
SUNSYNK-8KW
Sunsynk New 8Kw Hybrid Inverters are very efficient at managing power. It can combine and manage utility, solar and battery inputs to supply your load, as well as managing Generator inputs. It can be used purely as a backup inverter or a Solar Inverter to charge batteries and supply load or it can feed excess solar power back to the grid. The units can communicate with Various battery BMS’s and units can be monitored remotely via the sunsynk Dongle from anywhere there is wifi signal.
Sunsynk 100AH 10.65kWh 51.2V Battery (Built with CATL)
- Built with CATL Lithium Ion cells
- Operates at a Voltage of– 51.2V
- Capacity – 10.65kWh/208Ah
- Maximum (DoD) Depth of Discharge is – 100%
- IP40
- Voltage ( Cut off)– 45.6V
- Voltage (Bulk)– 56.16V
- Charging Current – 50A (Charge I)
- Maximum recommended discharge Charging Current – 50A
- Standard Discharging I – 50A
- Size 836 x 550 x 160 @ 90Kg
- Up to 8 in parallel
FEATURES
• Pure Sine wave input at 220V 1Phase.
• Back up, or grid tied.
• Automatic restart after grid fail and return.
• Programmable supply priority for battery or grid
• Programming AC or solar or generator as priority charging
• Built in protection against temp, overload and short circuit
• anti Islanding when AC fails.
• Sunsynk Wi-Fi remote monitoring with 2 x MPPT’s
Must be installed by a Qualified installer with a COC issued or warranty will be voided
Sunsynk 8kw Inverter Data Sheet
Sunsynk 10kw Battery Data Sheet
***EXCLUDES INSTALLATION- Supply only, we can recommend an installer
